Using Terraform to Provision a YugabyteDB Cluster

Using Terraform to Provision a YugabyteDB Cluster

Bhavin Gandhi
Bhavin Gandhi
9th October 2020
19 mins

This blog post is written by Infranaut – Bhavin Gandhi for Yugabyte.

HashiCorp’s Terraform is an infrastructure as code (IaC) tool as well as a framework. It is used for writing the infrastructure configuration in a declarative way using HashiCorp Configuration Language (HCL) or JSON. It has now become a preferred tool when it comes to provisioning infrastructure on different cloud platforms. This is mainly due to the wide range of supported providers and the extensible nature of the tool itself. One can write provider plugins, modules to extend Terraform.

In this blog post, we will be looking into the Terraform modules for provisioning YugabyteDB on different cloud providers. We will be focusing mostly on the terraform-aws-yugabyte module which is specific to Amazon Web Services (AWS) while pointing out minor differences in other modules. We will cover the topics including provisioning a cluster, managing nodes, understanding different configuration options, and more.

Summary of sections in this post

Provisioning a cluster on AWS

Let’s create a 3 node cluster using the terraform-aws-yugabyte module. Before starting with that, make sure you have installed Terraform on your machine. Follow these instructions for Terraform intallations. We are using Terraform v0.13.3 in this post.

Create a new Terraform configuration file deploy-yugabytedb.tf with the following contents:

module "yugabyte-db-cluster" {
  source = "github.com/yugabyte/terraform-aws-yugabyte"

  region_name = "us-east-1"
  vpc_id = "<vpc id>"
  availability_zones = ["us-east-1a", "us-east-1b", "us-east-1c"]
  subnet_ids = ["<subnet id from 1a>", "<subnet id from 1b>", "<subnet id from 1c>"]
  ssh_keypair = "yb-cluster-key"
  ssh_private_key = "/opt/keys/yb-cluster-key.pem"

  cluster_name = "yb-cluster"
  replication_factor = "3"
  num_instances = "3"
}

output "outputs" {
  value = module.yugabyte-db-cluster
}

Configuration variables

The values we set under the module block are the configuration variables for our terraform-aws-yugabyte module.

  • source is the location where the module is hosted. This can be a link to the Git repository or local path to the clone.
  • region_name is the AWS region where the cluster will be created.
  • vpc_id is the ID of a pre-existing VPC in the region_name.
  • availability_zones is a list of availability zones from the region_name above. The cluster nodes are distributed across these zones.
  • subnet_ids is a list of subnets corresponding to the availability zones. The first subnet should belong to the first zone from availability_zones list and so on.
  • ssh_keypair is the name of the AWS EC2 keypair which is already present in the AWS account. This is used to connect with the nodes.
  • ssh_private_key is the local path to the .pem file of the above keypair.
  • allowed_sources specifies a list of allowed CIDR source blocks in the security group. We will be talking more about this shortly.
  • cluster_name is used for naming different resources in AWS.
  • replication_factor controls the replication of the data in the YugabyteDB cluster. Read more about replication factor (RF) here.
  • num_instances specifies the number of instances to create for this cluster. This number must be greater than or equal to the replication_factor.

Take a look at the variables.tf file for a complete list of supported configuration variables.

The output block of deploy-yugabytedb.tf specifies which values to print once the Terraform stack is created. In our case we are printing all the output values from yugabyte-db-cluster, which we have defined using the module block.

AWS access credentials

To set the required AWS configuration and credentials, export following environment variables with appropriate values.

export AWS_ACCESS_KEY_ID="AKIAIOSFODNN7EXAMPLE"
export AWS_SECRET_ACCESS_KEY="wJal/…/bPxRfiCYEXAMPLEKEY"

Take a look at the environment variables section from the AWS Provider docs for more information.

NOTE: The method to pass access credentials to Terraform is provider specific. These details are given in the documentation for the respective modules – terraform-gcp-yugabyte and terraform-azure-yugabyte (and in this post for AWS).

With all the housekeeping done, let’s create our cluster now.

To initialize the Terraform directory where we have created the deploy-yugabytedb.tf file, run the following command.

$ terraform init

Initializing modules...
Downloading github.com/yugabyte/terraform-aws-yugabyte for yugabyte-db-cluster...
- yugabyte-db-cluster in .terraform/modules/yugabyte-db-cluster

Initializing the backend...

Initializing provider plugins...
- Finding latest version of hashicorp/null...
- Finding hashicorp/aws versions matching "~> 3.0"...
- Installing hashicorp/null v2.1.2...
- Installed hashicorp/null v2.1.2 (signed by HashiCorp)
- Installing hashicorp/aws v3.7.0...
- Installed hashicorp/aws v3.7.0 (signed by HashiCorp)

Terraform has been successfully initialized!

This will download the terraform-aws-yugabyte module as well as other dependencies like plugins.

To see the list of resources we will be creating as part of this deployment, run the following command.

$ terraform plan

Refreshing Terraform state in-memory prior to plan...

module.yugabyte-db-cluster.data.aws_ami.yugabyte_ami: Refreshing state...

------------------------------------------------------------------------

An execution plan has been generated and is shown below.
Resource actions are indicated with the following symbols:
  + create

[Terraform](/terraform-consulting/) will perform the following actions:

  # module.yugabyte-db-cluster.aws_instance.yugabyte_nodes[0] will be created
  + resource "aws_instance" "yugabyte_nodes" {
      + ami                          = "ami-0affd"
      + arn                          = (known after apply)
      + associate_public_ip_address  = true
      + availability_zone            = "us-east-1a"
      + instance_type                = "c4.xlarge"

      + root_block_device {
      + volume_size           = 50
      + volume_type           = "gp2"
    }
    }

  # module.yugabyte-db-cluster.aws_security_group.yugabyte will be created
  + resource "aws_security_group" "yugabyte" {
      + arn                    = (known after apply)
      + description            = "Managed by Terraform"
      + egress                 = (known after apply)
      + id                     = (known after apply)
      + ingress                = [
      + {
          + cidr_blocks      = [
          + "0.0.0.0/0",
        ]
          + description      = ""
          + from_port        = 22
          + protocol         = "tcp"
        },
    ]
      + vpc_id                 = "vpc-dab123"
    }

  # module.yugabyte-db-cluster.null_resource.create_yugabyte_universe will be created
  + resource "null_resource" "create_yugabyte_universe" {
      + id       = (known after apply)
      + triggers = (known after apply)
    }

Plan: 6 to add, 0 to change, 0 to destroy.

The above output is redacted for brevity. If everything looks good, we can run the following command to create the actual resources.

$ terraform apply

# …
Plan: 6 to add, 0 to change, 0 to destroy.

Do you want to perform these actions?
  Terraform will perform the actions described above.
  Only 'yes' will be accepted to approve.

  Enter a value: yes

Apply complete! Resources: 6 added, 0 changed, 0 destroyed.

Outputs:

outputs = {
  "JDBC" = "postgresql://yugabyte@35.135.36.37:5433"
  "YCQL" = "ycqlsh 35.135.36.37 9042"
  "YEDIS" = "redis-cli -h 35.135.36.37 -p 6379"
  "YSQL" = "ysqlsh -U yugabyte -h 35.135.36.37 -p 5433"
  "master-ui" = "http://35.135.36.37:7000"
  "private_ips" = [
    "10.0.0.14",
    "10.0.0.30",
    "10.0.0.45",
  ]
  "public_ips" = [
    "35.135.36.37",
    "35.135.36.38",
    "35.135.36.39",
  ]
  "security_group" = "sg-00e12"
  "ssh_key" = "/opt/keys/yb-cluster-key.pem"
  "ssh_user" = "centos"
  "tserver-ui" = "http://35.135.36.37:9000"
}

To check the status of the cluster, we can visit one of the masters’ web UI at http://35.135.36.37:7000.

check-the-status-of-the-cluster

Make sure you persist the Terraform state. It is a record of real world state and metadata of our resources. It is used when we apply the changes made to our infrastructure code. It’s usually saved as a file with name terraform.tfstate in the same directory as the configuration file when using the default configuration.

To check the connectivity to the YCQL and YSQL APIs, we can run following command line clients:

$ docker run --rm -it yugabytedb/yugabyte-client ysqlsh -h 35.135.36.37

ysqlsh (11.2-YB-2.2.0.0-b0)
Type "help" for help.

yugabyte=# \conninfo
You are connected to database "yugabyte" as user "yugabyte" on host "35.135.36.37" at port "5433".
$ docker run --rm -it yugabytedb/yugabyte-client ycqlsh 35.135.36.37

Connected to local cluster at 35.135.36.37:9042.
[cqlsh 5.0.1 | Cassandra 3.9-SNAPSHOT | CQL spec 3.4.2 | Native protocol v4]
Use HELP for help.
cqlsh> SHOW HOST;
Connected to local cluster at 35.135.36.37:9042.

Running client workload

As we have the cluster up and running, now we will run some client workload on it. We will be using the YugabyteDB workload generator container image to do so. This application will connect to the cluster like a real world application will. It will try to insert, retrieve, and update the data.

To run the application, execute the following command:

$ docker run --rm -it yugabytedb/yb-sample-apps \
            --workload SqlInserts \
            --nodes 35.135.36.37:5433 \
            --num_threads_write 1 \
            --num_threads_read 4

…
105109 [Thread-1] INFO com.yugabyte.sample.common.metrics.MetricsTracker  - Read: 9.60 ops/sec (409.58 ms/op), 718 total ops  |  Write: 2.40 ops/sec (409.58 ms/op), 185 total ops  |  Uptime: 100043 ms |

After running for a few minutes, we can see the new tablets and increased read write operation metrics. To view the list of tablet servers, visit http://35.135.36.37:7000/tablet-servers.

new-tablets-and-increased-read-write-operation-metrics

High availability of the cluster

To ensure high availability (HA) of the data, it is recommended to at least have replication factor (RF) of 3. For replication factor of 3, the cluster needs to have at least 3 nodes, with YB-Master and YB-TServer running on all of them. If the supplied replication_factor is greater than the num_instances, then the stack creation will fail.

To make the cluster tolerant to availability zone (AZ) failures, it’s better to use a number of availability zones which is greater than or equal to the RF. In our example, we are using 3 AZs (us-east-1a, us-east-1b, and us-east-1c).

The cluster provisioning script starts YB-Masters equal to the given RF. It also tries to make sure that they are spread across the given AZs.

For example, if we have RF of 3, 3 AZs (a, b, c), and 6 nodes, then the script will start a total of 6 nodes, and 3 of them will have YB-Master running on them. The 3 YB-Masters will be running on one node from each of the AZs – a, b, and c. All 6 nodes will have the YB-TServer process running on them.

You can read the documentation sections Replication factor, High availability, and Fault tolerance for more information.

NOTE: The terraform-gcp-yugabyte module automatically selects all the availability zones from the given region. Basically, we don’t have to pass the AZ or subnet list.

Scaling the YB-TServer nodes

The YB-TServer process / service from the cluster is responsible for the user IO. It stores all the tablets (the user data). Client communication happens with this service.

You might need to scale this service horizontally in case of more storage or throughput requirements. In our case, this translates to increasing the number of nodes we have in the cluster.

Scaling out the nodes

To increase the number of nodes, modify the deployment configuration in deploy-yugabytedb.tf with a new value of num_instances.

module "yugabyte-db-cluster" {
  # …
  num_instances = "5"
}

Applying these changes will add two new nodes to the cluster while keeping other nodes untouched.

$ terraform plan

Terraform will perform the following actions:

  # module.yugabyte-db-cluster.aws_instance.yugabyte_nodes[3] will be created
  …
  # module.yugabyte-db-cluster.aws_instance.yugabyte_nodes[4] will be created
  …
  # module.yugabyte-db-cluster.null_resource.create_yugabyte_universe must be replaced
-/+ resource "null_resource" "create_yugabyte_universe" {
      ~ id       = "1450910725944170537" -> (known after apply)
      ~ triggers = {
      - "cluster_instance_ids" = "i-0a32,i-08b5,i-0a25"
    } -> (known after apply) # forces replacement
    }

Plan: 3 to add, 0 to change, 1 to destroy.

$ terraform apply

…
Apply complete! Resources: 3 added, 0 changed, 1 destroyed.

Outputs:
…

The newly added YB-TServers should be visible in the YB-Master UI at http://35.135.36.37:7000/tablet-servers. These newly added TServers will automatically pick up tablets from the existing TServers to balance the distribution of tablets.

see-new-servers-in-UI

Scaling back the nodes

The scale down operation is a special operation as directly terminating nodes might result in data loss.

For example, if we terminate one node from a cluster with RF 3 and 6 nodes, YB-Master will mark the node as dead after a configurable amount of time. It will use 2 other replicas to recover the tablets and replicate those to some other node. If we try to terminate more than or equal to RF number of nodes at the same time, then it might result in complete deletion of a tablet in a non-recoverable way.

Let’s scale down the newly added nodes from the cluster. Those are the ones with private IPs 10.0.0.10 and 10.0.0.22. Make sure any of the nodes you are scaling down don’t have the YB-Master process running on them. This can be checked by going to the YB-Master UI at http://35.135.36.37:7000/.

NOTE: You can run terraform output to get the output of the Terraform stack at any time.

First, let’s move all data out of the nodes that we are going to remove from the cluster. SSH into the first master node and run the following commands:

$ ssh -i /opt/keys/yb-cluster-key.pem centos@35.135.36.37
[centos@ip-10-0-0-14 ~]$ export YB_MASTERS="10.0.0.14:7100,10.0.0.30:7100,10.0.0.45:7100"
[centos@ip-10-0-0-14 ~]$ /home/centos/yugabyte-db/master/bin/yb-admin \
               -master_addresses $YB_MASTERS \
               change_blacklist ADD 10.0.0.10:9100 10.0.0.27:9100

This exports the private IPs of all the master nodes. It modifies the blacklist to add the two nodes which we want to remove.

To verify that the nodes are added correctly, run the following command:

[centos@ip-10-0-0-14 ~]$ /home/centos/yugabyte-db/master/bin/yb-admin \
               -master_addresses $YB_MASTERS \
               get_universe_config

{
  "version": 7,
  …
  "serverBlacklist": {
    "hosts": [
      {
    "host": "10.0.0.10",
    "port": 9100
      },
      {
    "host": "10.0.0.27",
    "port": 9100
      }
    ],
    "initialReplicaLoad": 13
  },
}

Once the nodes are added into the blacklist, YB-Master will start moving out the data from them to other nodes. To check the progress of the data move, run the get_load_move_completion command. Run the command periodically to see the progress.

[centos@ip-10-0-0-14 ~]$ /home/centos/yugabyte-db/master/bin/yb-admin \
               -master_addresses $YB_MASTERS \
               get_load_move_completion
Percent complete = 53.8466 : 6 remaining out of 13

[centos@ip-10-0-0-14 ~]$ /home/centos/yugabyte-db/master/bin/yb-admin \
               -master_addresses $YB_MASTERS \
               get_load_move_completion
Percent complete = 100 : 0 remaining out of 13

Now the YB-Master UI should show that the two nodes have 0 tablets. The next step is to modify our Terraform configuration. We will set num_instances back to 3 and apply the changes.

caling-back-nodes-YugabyteDB

$ terraform plan

Terraform will perform the following actions:

  # module.yugabyte-db-cluster.aws_instance.yugabyte_nodes[3] will be destroyed
  - resource "aws_instance" "yugabyte_nodes" {
      - id                           = "i-0a95" -> null
      - private_dns                  = "ip-10-0-0-10.ec2.internal" -> null
      - private_ip                   = "10.0.0.10" -> null
      - public_ip                    = "35.135.36.40" -> null
      - …
    }

  # module.yugabyte-db-cluster.aws_instance.yugabyte_nodes[4] will be destroyed
  - resource "aws_instance" "yugabyte_nodes" {
      - id                           = "i-0dab" -> null
      - private_dns                  = "ip-10-0-0-27.ec2.internal" -> null
      - private_ip                   = "10.0.0.27" -> null
      - public_ip                    = "35.135.36.41" -> null
      - …
    }

  # module.yugabyte-db-cluster.null_resource.create_yugabyte_universe must be replaced
-/+ resource "null_resource" "create_yugabyte_universe" {
      ~ id       = "5810245081236049803" -> (known after apply)
      ~ triggers = { # forces replacement
      ~ "cluster_instance_ids" = "i-0a32,i-08b5,i-0a25,i-0a95,i-0dab" -> "i-0a32,i-08b5,i-0a25"
    }
    }

Plan: 1 to add, 0 to change, 3 to destroy.

$ terraform apply

…
Apply complete! Resources: 1 added, 0 changed, 3 destroyed.

Remove the nodes from the blacklist; this will avoid issues if a node with the same IP address is added later to the cluster.

$ ssh -i /opt/keys/yb-cluster-key.pem centos@35.135.36.37
[centos@ip-10-0-0-14 ~]$ export YB_MASTERS="10.0.0.14:7100,10.0.0.30:7100,10.0.0.45:7100"
[centos@ip-10-0-0-14 ~]$ /home/centos/yugabyte-db/master/bin/yb-admin \
               -master_addresses $YB_MASTERS \
               change_blacklist REMOVE 10.0.0.10:9100 10.0.0.27:9100

Once the nodes are terminated, YB-Master will show those as dead. As of now there is no way to remove those entries without restarting the leader YB-Master node (this will change in the future).

$ ssh -i /opt/keys/yb-cluster-key.pem centos@35.135.36.39
[centos@ip-10-0-0-45 ~]$ kill -TERM $(pgrep yb-master); sleep 10s; ./start_master.sh
yb-master process is not running - restarting..

Take a look at the Perform data move section from the ‘Change cluster configuration’ page for more information.

Security group configuration

The default value of the configuration variable allowed_sources is ["0.0.0.0/0"]. This allows anyone to access the nodes from our cluster. The default configuration is only for usability purposes and it’s recommended to change it.

The value can be set to a list of CIDR blocks and security group IDs. This can be an office IP address, CIDR block of the VPC or some specific security group. That way the cluster nodes will be accessible only from those IPs. The allowed ports are YB-Master UI (7000), YB-TServer UI (9000), Yedis (6379), YCQL (9042), YSQL (5433), and SSH (22). For example, setting the value to ["1.2.3.4/32", "5.6.7.8/32"] will allow connections from these IP addresses only.

Refer to the Security groups for your VPC document from AWS for more information.

NOTE: The security group restriction is only available in the AWS module as of now. Similar configuration will be added to the modules for GCP and Azure soon.

Conclusion

That’s it! You now have a YugabyteDB cluster running on AWS that was provisioned using Terraform. To recap, in this blog post, we showed you how you can use Terraform modules for provisioning YugabyteDB on different cloud providers. We walked you through provisioning a cluster, managing nodes, understanding different configuration options. For the official documentation, usage description, and code, check out the AWS/Terraform page on GitHub.

Infracloud logo

Adopt Cloud Native Faster with InfraCloud's Expertise

Consult Cloud Native Experts

Posts You Might Like

Databases

Is KeyDB 5x Faster than Redis? We Tested!

Learn about InMem DB as we benchmark Redis and KeyDB in different scenarios to determine the best choice for a fast in-memory database application.
Nagaraju Rapelli Nagaraju Rapelli
Sonali Srivastava Sonali Srivastava
InfraCloud Team
26th June 2024 29 mins
Databases

Multi-Region YugabyteDB Deployments on Kubernetes with Istio

Learn how to set up a multi-cluster Kubernetes environment spanning across multiple regions with the help of Istio.
Bhavin Gandhi
Bhavin Gandhi
20th July 2021 12 mins

This website uses cookies to offer you a better browsing experience
